Hettich Intermat 9936 W45 95˚ Overlay Hinge 48096 TH52
Regular price
£8.99
inc. VAT
Couldn't load pickup availability
Why not share this product on your favourite social networks:
Hettich Intermat 9936 W45 Hinge. 95 degrees overlay sprung hinge with TH52 drilling pattern. Price is for one hinge.
Please note hinge mounting plates and screws are not included, please purchase separately.
Please note hinge mounting plates and screws are not included, please purchase separately.
- Intermat angle hinge W45
- With self closing feature (Intermat 9936 W45)
- Quality classification under EN 15570, Level 2
- Opening angle 95°
- For door thickness 14 - 32 mm
- Door mounting option overlay (B 0)
- TH - drilling pattern 52 x 5.5 mm
- Cup depth 10.5 mm
- Installation for screwing on
- Integrated overlay adjustment +2 mm / -2 mm
- Integrated depth adjustment +2 mm / -2 mm
- Height adjustment at mounting plate
- Steel / die-cast zinc nickel plated
